POLYGONAL SYNTHESIS

• ORDER - Set the overtones
• Order defines the number of corners on the polygon, which can range from a line (order 2) to an almost perfect circle (order 28) with all fractional settings in between. The number of corners defines the ratio of overtones with respect to the fundamental frequency: a low count keeps the harmonics near the fundamental frequency, a high order shifts them up.

• TEETH - Bite through the mix
• Teeth was the first happy accident while playing with the core formula of polygonal synthesis. It tilts the sides of the polygon out of the normal orientation and can be used to control the loudness of the overtones. It creates discontinuities in the waveform and acts as balance between the fundamental frequency and the overtone spectrum.
• ROLL - Animate the spectrum
• Polygogo is a stereo oscillator. The output channels are derived directly from the X and Y pixel information, which means that both channels are slightly different most of the time. This leads to a great perception of space without any external effects. To animate the spectra of the two channels and create spatial movement, Roll rotates the object around the center and animates the waves.

• OPERATOR - Modulate with precise ratios
• One of the benefits of a digital oscillator core is precise frequency tracking for linear FM modulation. Here, the builtin operator modulates the fundamental frequency for FM madness. FM Ratio is settable and quantizable, FM Amount goes from subtle growls in the lows to aliasing madness at high frequencies.

• FOLD - Overflow waves to the other side
• Fold was the second happy accident while this instrument was created. Fold overflows the wave to the other side, leading to tickling noise at low settings and crushing and slicing the waveform to total distortion when fully turned up. This digital artifact was reproduced in analog circuitry and delivers the most crisp and open sound.

• High contrast OLED display
• 6 long range sliders with dust covers
• 8 high torque potentiometers
• 11 mini jack connectors for inputs and outputs
• 3 push buttons and leds
• Original Polygonal Synthesis core
• Builtin FM operator
• Low frequency panning modulator
• Analog wave overflow output stage
• 2x high speed V/oct and exponential FM inputs
• (24 bit / 96 kHz)
• 6x actively filtered CV inputs
• (16 bit / 6 kHz)
• 1x trigger input for hard sync
• 1x stereo output

Width: 32HP

Max Depth: 26mm

Power: 110mA @+12V , 15mA @-12V
